材料

Materia

冷轧钢板

Cold rolled steel sheet

表面处理

Surface

treatment

台体磷化底涂处理，外部为粉

末涂层，颜色可分RAL7032和

RAL7035两种织纹，安装板则为 镀锌

Cabinet is applied with etch

primer and covered with powder coating on the outer side. Two    color textures, RAL7032 and

RAL7035, are available. The  mounting plate is galvanized.

防护等级

Protection

grade

IP54(按GB4205-1993)

IP54 (in accordance with

GB4205-1993)

标准配置

Standard

configuration

前单(双)门、操作台面、柜体、安 装板、门锁、密封条、液压支撑  Front single (dual) door,

operating console board,

cabinet body, mounting plate, door lock, sealing strips and   hydraulic support

钢板厚度

Thickness of steel sheet

箱体: 2.0mm  门板: 2.0mm

操作台面: 2.0mm

安装板: 2.5mm

Cabinet body: 2.0mm

Door plate: 2.0mm

Operation console board:2.0mm

Mounting plate: 2.5mm
